Grade: Mo1 Mola TZM
Standard: GB/T4188-1984
Surface condition: Black, Alkali wash, Bright, polished.
Chemical composition
Fe | Ni | Al | Si | Ca | Mg | P | C | O | N | Mo |
0.005 | 0.003 | 0.002 | 0.002 | 0.002 | 0.002 | 0.001 | 0.006 | X | 0.003 | other |
Moly rod with Dia.30mm Max. , O:≤0.003%; Moly rod with Dia.30-Dia.80, O≤0.005%; Moly rod with Dia.80mmMin, O≤0.01% | ||||||||||
Product Specification
Product Name | Diameter | Tolerance |
Forged molybdenum rod | >80mm | +/-2.0mm |
25mm-80mm | +/-1.0mm | |
Rotary forged molybdenum rod | 10mm-25mm | +/-0.2mm |
3.0mm-10mm | +/-0.1mm | |
Bright molybdenum rod | >20mm | +/-0.2mm |
Straightened molybdenum rod | 0.5mm-3.0mm | +/-0.03mm |
Polished molybdenum rod | 0.8mm-50mm | +/-0.2mm |
The molybdenum rod mainly used in the manufacture of electric vacuum parts, guide rod, electrode, lead wire, high temperature parts, furnace heating rod and so on.
Exceptional Strength & Stiffness
High Purity
Excellent Creep Resistance
Good Machinability
High Dimensional Stability
Excellent Corrosion Resistance
Low Emissivity and Vapor Pressure
Good Electrical Conductivity
Low Thermal Expansion
Excellent Thermal Conductivity
